HOW WE CAN HELP TO ANALYZE CONCRETE SCANS

If you’d like help with analyzing data from your scans using our Hilti PS 250 Ferroscan or Hilti PS 1000 X-Scan detection systems, then you can contact your local Hilti team.

We have Hilti experts who can look at your scan data and optimize the data for you, exporting it in the needed format in 2D or 3D.

This covers:

Rebar

Find the location of the reinforcing bars and estimate the depth of concrete cover and rebar size – based on scan data from our Hilti PS 250 Ferroscan. This is important for as-build checks, structural renovation work or retrofitting.

Layout and type of objects

Analyze the layout of objects, using scan data from our Hilti PS 1000 X-Scan detection system. Find rebar, live wires, metal or plastic pipes and more, and analyze their layout over a wide area and multiple layers.

• We offer an hourly service for a single scan or a daily service for multiple scans.
• We can provide both an analysis of your scan data and detailed documentation – including statistics reports.
• We use our Hilti PROFIS Detection software to conduct our analysis.

Please contact your local Hilti team for more information.
